Specification :
– 3.3v to 5v operation, with onboard I2C level shifter
– Temperature detection of two-dimensional area: 8 × 8 (64 pixels)
– Temperature range of 0°c to +80°c
– Temperature accuracy of +/- 2.5°c
– Human detection at up to 7m
– Viewing angle 60°, optical axis gap 5.6°
– Current consumption 4.5mA
– Module defaults to I2C address 0xD2, changeable to 0xD0
– Weight is only 3g
– Size 24mm x 21mm
